Application
Only suitable for terminal fiber splicing with low splicing precision requirements, very small quantities, and a relatively good construction environment (dust, temperature, altitude).
Features
Precise fiber core alignment with ultra-low fusion splice loss.
Fast fusion splicing in 7 seconds, highly efficient heating in 18 seconds.
320x image magnification, 5mm fusion splicing for ultra-short cut-length fibers, 300 groups of fusion modes, 100 groups of heating modes.
10,000 groups of fusion records, storage of 64 images
Ceramic fiber presser, ceramic v-groove, all-in-one accessory
Bidirectional splicing, automatic splicing, intelligent arc calibration.
USB and SD card interfaces, automatic software update via USB drive.
Integrated modular lithium battery, supports 220 splice-and-heat cycles.
Technical Parameters
| Model | AV6481 |
| Alignment method | Precise core and cladding alignment. |
| Applicable fibers | Any common optical fiber, rubber-insulated fiber and patch cords meeting ITU-T G.651~653, ITU-T G.655 and ITU-T G.657 requirements. |
| Optical fiber diameter | Cladding: 80-150μm, coating layer: 0.1-3mm |
| Cutting length | 5~16mm (coated optical fiber diameter ≤250μm); 10mm (coated optical fiber diameter: 0.25~3mm) |
| Fusion splice consumption (typical value) | 0,02 dB (SMF); 0,01 dB (MMF); 0,04 dB (DSF); 0,04 dB (NZDSF) |
| Return Loss: | >>60 dB |
| Splicing time: | 7S |
| Estimated splice loss: | Available |
| Heating time: | 18S |
| Protective sleeve length: | 60mm, 40mm and a series of heat-shrink tubes |
| Graphic display | High-performance 4.3-inch LCD screen |
| Expansion time | 320 veces/88 veces |
| Fusion splice records | 10000 grupos |
| Battery capacity | 11.1V, 6400mAh, typically 220 fusion splice-and-heat cycles. |
| Battery life | Cycle charge times reach 300~500, replaceable by customers. |
| Electrode life | Typically 4000 times, replaceable by customers. |
| Work illumination | Built-in high-brightness LED with wide illumination area. |
| Working environment | Temperature: -10~50℃; humidity: 0~95% RH; altitude above sea level: 0~6000m |
| Operation interfaces | Graphical user interface (GUI) |
| External power supply | CA: 100-240 V, 60 Hz, 0-1.5 A; CC: 10-15 V |
Frequently Asked Questions
Q: What alignment technology is used?
A: Core-alignment models are available for lowest splice loss, as well as clad-alignment models for cost-effective field splicing.
Q: What is the typical splice loss?
A: Typical splice loss is 0.02dB for single-mode and 0.01dB for multi-mode fiber, verified automatically by the built-in arc test after each splice.
Q: How many splices per battery charge?
A: Typically 200–320 splice cycles per full charge depending on the model; the AC adapter is included for continuous operation.
Q: Which fiber types are supported?
A: It supports single-mode (G.652/G.657), multi-mode and DS fiber in 250µm, 900µm, 2.0mm and 3.0mm configurations with the appropriate fiber holders.
Q: What training and after-sales support is provided?
A: We provide operation guidance and videos, spare electrodes and blades, and responsive after-sales technical support by message or remote assistance.
